Natural Rubber Water Based Tap | SPIRIT INNOTECH INC

Product Natural Rubber Water Based Tap

Non-adhesive Tape
Can also be called compartment paper tape
Great tensile strength, not easy to break during production process
Applies and unwinds smoothly
Semi-adhesive Tape
Strong toughness, not easy to break, good fixation, and will not have glue residue on the copper
Significant reduce the cost of automatic production
Made from Kraft paper which offers great strength and adhesion power
Low tack quality secures smooth production without intermittence
Specially long length of the tape can reduce change over time and minimize numbers of tapes needed
Cold-pressed Paper Tape
Slightly glued surface which able to withstand the weight of ceramic capacitor

Non-adhesive Tape
Used in axial taping for electronic components sequencing
Work with masking tape for applying to electronic resistors and to auto- belting system
Applies and unwinds smoothly
Semi-adhesive Tape
Designed for electronic components pre-production sequencing
Used as a temporarily bonding strips before electronic insertion production
Cold-pressed Paper Tape
Apply to metal spray-masking during production of metal film capacitors.
Applied to capacitor and row of strip production coating arrangement
Designed for electronic component pre-production sequencing
Used as a temporarily bonding strip before electronic insertion production

Product	Color	Products Form	Adhesive Type	Total Thickness	Peel adhesion (ASTM-D100	Elongation (ASTMD-1000)	Tensile strength (ASTMD-1000)
Non-adhesive Tape SP-220B	Brown	Jumbo，Finished roll	0.11mm	7.5kg/15mm	4.8kg/15mm	100	120
Semi-adhesive Tape SP-230B	White，Red	Jumbo，Finished roll	Water-based natural rubber	0.1mm	150g/15mm	0.25%	0.6kg/6mm
Cold-pressed Paper Tape SP-530B	Brown	Jumbo，Finished roll	Water-based natural rubber	0.13mm	700g/15mm	3%	14kg/cm
Cold-pressed Paper Tape SP-530W	White	Jumbo，Finished roll	Water-based natural rubber	0.13mm	700g/15mm	3%	14kg/cm
